Large SUS301 Flat Wire Compression Spring 4mm Hourglass Cylindrical Structure

Grande immagine : Large SUS301 Flat Wire Compression Spring 4mm Hourglass Cylindrical Structure

Dettagli:

Luogo di origine:	Cina
Marca:	Liyu
Certificazione:	ISO14001；ISO13485；IATF16949
Numero di modello:	Molla di compressione

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 set
Prezzo:	Negoziabile
Imballaggi particolari:	Imballaggio standard per l'esportazione
Termini di pagamento:	L/C, T/T

Contatto Ora chiacchieri

Large SUS301 Flat Wire Compression Spring 4mm Hourglass Cylindrical Structure

descrizione

Nome:	Molla di compressione	Diametro del filo:	0,05–20 mm o personalizzato
OEM/ODM:	Supportato	Campione:	Disponibile
Disegno:	PDF/CAD/STEP/IGES/DWG	Certificazione:	ISO13485；ISO14001；IATF16949
Trattamento superficiale:	Zincato, Nichelato, Cromato, Ossido nero, Elettroforesi, Verniciatura a polvere, Passivazione, Nessu	Tipo di fine:	Estremità chiuse, Estremità aperte, Estremità molate, Estremità chiuse e molate
Applicazione:	Automotive, medicale, elettronica, attrezzature industriali, macchine agricole, aerospaziale, prodot	Materiale:	Acciaio inossidabile (304, 316, 302), filo armonico, acciaio al carbonio, filo temperato ad olio, cr
Evidenziare:	SUS301 flat wire compression spring , 4mm flat wire compression spring , Hourglass 4mm compression spring

Compression spring·CUSTOMIZATION

Small compression springs are widely used in electronics, switches, instruments, consumer products, and precision devices. Our miniature compression springs are manufactured with high accuracy and excellent elasticity to ensure smooth operation and reliable performance. We can produce small diameter springs with customized designs, materials, and specifications for different applications.

Technical parameters of cylindrical spiral compression spring

To customize the compression spring, you need to provide the following necessary parameter information:
Wire diameter d: mm	(Note: the diameter of the spring wire)
Outer diameter D2: mm	(Note: the diameter of the outer circle of the spring)
Length L0: mm	(Note: the free height of the spring)
Number of circles Na: circle	(Note: the total number of turns of the spring)
For customized compression springs, you also need to provide the following technical requirements:
turn around:	(Description: Left-handed Right-handed)
Material requirements:	(Such as: stainless steel wire SUS, carbon steel wire SWC, piano wire SWP, copper wire... etc.)
Surface treatment:	(Description: blackening/galvanizing/nickel plating/chrome plating/baking paint/powder spraying/electrophoresis/shot peening/dacromet/electrolytic polishing...etc.)
End form:	(Explanation: TightenGrindTightly polish)
Strength requirements:	(Note: Elastic performance, other technical requirements, etc.)

Spring end characteristics

Characteristic	Parameter
Structural Features	Cylindrical
	Hourglass
	Shrink both ends
	Fixed pitch
	Conical
	Closed at both ends
	The ends are flat
	Variable pitch
	Barrel
	Two End opening
	The ends are not flat
Surface treatment	Blackening
	Shot Peening
	Apply anti-rust oil
	Zinc plating
	Polishing
	Electrolytic polishing
	Nickel plating
	Dacromet
	Teflon spray
Materials	Carbon spring steel wire SWC
	Piano wire SWPB
	Stainless steel wire SUS301, SUS302, SUS304, SUS316, SUS631
	65Mn
	82B
	55CrSi (SWOSC-V)
	Nickel-plated wire, galvanized wire
	Copper wire, phosphor copper wire, beryllium copper wire
	Square wire, flat wire, semicircular wire
	Alloy material wire
	Other special specifications steel wire
Wire diameter specifications	0.1~6mm
